| Brand Name : | RECOLUX |
| Model Number : | RIP5S-60-S1 |
| Certification : | ENEC, CE, RoHS, CB |
| Price : | Negotiable |
| Payment Terms : | T/T, L/C, Paypal |
| Supply Ability : | 20,000 Pieces per Month |
| Delivery Time : | 3-5 working days for sample, 7-15 working days for mass production |
Seamless LED Linear Ceiling Light Different Distribution 5/7/11 Cores
Datasheet for LED module:
| Model NO. | Wattage | Lumen | Efficacy | Function | EEC | Dimension(mm) |
| RIP5S-60-S1 | 60W-50W-42W-32W | 9,000lm | 160LM/W | ON/OFF | A++ | 1440*65*27 |
| RIP5S-60-V1 | 60W-50W-42W-32W | 9,000lm | ||||
| RIP5S-68-PC | 68W-60W-54W-48W-38W 32W-25W-20W by switch | 10,500lm | ||||
| RIP5S-72-B3 | 72W-68W-64W-60W-56W-54W-52W-50W-48W-45W | 10,500lm | 0-10V | |||
| RIP5S-68-T4 | Max 68W | 10,500lm | DALI |
Datasheet for trunkings:
| Item | Model NO | Wires(mm²) | Dimensions(mm) | Weight(KG) |
| 1 | TKB5-05W-00 | 5 x2.5 mm² | 1440x 65 x 65 | 1.59 |
| 2 | TKB5-07W-00 | 7 x2.5 mm² | 1.65 | |
| 3 | TKB5-11W-00 | 11 x2.5 mm² | 1.95 | |
| 4 | TKB9-05W-00 | 5 x2.5 mm² | 2880x 65 x 65 | 2.85 |
| 5 | TKB9-07W-00 | 7 x2.5 mm² | 2.98 | |
| 6 | TKB9-11W-00 | 11 x2.5 mm² | 3.25 |
Applications:
FAQ:
Q1. What are the installation methods?
A: Surface mounting/suspension.
Q2: Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm
the design firstly based on our sample.
Q3: Do you have OEM or ODM experience?
A: Yes, we focus on led lighting for years and have lots of big
cases. We are able and will be happy to be your official supplier.
For more information, welcome to visit our website www.recolux.com.
|
|
